Homelift Vuelift Mini
The panoramic glass elevator with integrated shaft.
An extraordinary homelift whose riding experience goes beyond comfort. Both the cabin and the shaft are equipped all around with high-quality acrylic or diamond glass, providing a clear view into the open spaces, making the ride a special experience. Due to its design, the Vuelift is suitable for many applications.
| Reduced overhead | 2440 mm from the floor level of the last floor is sufficient. |
| Pitless elevator | A pit of 76 mm or a ramp is sufficient. |
| Space-saving | With a footprint of 1.27 meters in diameter, it takes up to 0.9 square meters less space than a conventional elevator. |
| Everything's included | The Vuelift Mini comes with the shaft included, thus eliminating the need for on-site shaft construction and reducing space requirements. |
Vuelift Mini in the staircase of a villa
Technical specifications
| Drive system | Drum drive with integrated brake |
| Motor control | Frequency converter |
| Motor power | 1.85 kW |
| Load capacity | 226 kg |
| Travel speed | 0.15 m/s |
| Power supply | 230 V / 50z / 16A |
| Operation | Impulse |
| Lifting height | 17.6 m |
| Number of stops | max 6 |
| Cabin entrances | max 6 |
| Access sides | Single-sided or double-sided (1 entrance per landing) |
| Shaft headroom | min 2440 mm |
| Floor-to-floor distance | min 2375 mm |
| Ceiling height | min 2236 mm |
| Shaft pit | 80 mm or without with compensation ramp |
| Cabin diameter | ø 1’000 mm |
| Cabin height | 1970 mm |
| Control cabinet | Width 500 mm Depth 800 mm Height 280 mm (maximum distance 25000 mm cable length) |
Floor plan of Vuelift Mini
Bottom landing / Ceiling opening
When installed in a situation with one, two, or three-sided on-site enclosure, there are no minimum clearances to observe, but cleaning of the shaft exterior should be facilitated.
Pit ring to door edge min. 1912 mm
We have the perfect solution for you.
Contact our specialists for a free consultation.
-
Meet our sales team
We're here to help you find the right lift solution for your needs. Give us a call!
-
Enrico Ghidotti
Sales Manager Switzerland
Contact / Regions:
AI, AR, SG, SH, TG, TI, ZG, ZH
Phone: 041 854 78 23
Mobile: 079 251 42 26
enrico.ghidotti@garaventalift.ch -
Marcel Wicki
Sales Consultant
Contact / Regions:
AG, GL, GR, LU, NW, OW, SZ, UR
Phone: 041 854 78 27
Mobile: 079 373 62 56
marcel.wicki@garaventalift.ch -
Marcel Schulz
Sales Consultant
Contact / Regions:
BE, BL, BS, FR, VS, SO
Phone: 041 854 78 28
Mobile: 079 303 60 03
marcel.schulz@garaventalift.ch
Safety is standard
The Vuelift Mini meets or exceeds the requirements of ASME A17.1 / CSA B44 as well as local codes. Standard safety features include an emergency stop switch, safety brakes, a speed regulator, manual lowering, and an emergency battery backup for lighting and cabin lowering. This means you should never have to worry about most safety risks - even in the event of a power outage, your elevator will safely descend you.
Motor Integrated in Shaft - Savaria Vuelift Mini
Savaria Vuelift Mini on the Upper Floor
Enjoy the golden years at home
Enjoy a flexible lifestyle both today and in the future. Integrating the Vuelift Mini means more comfort, improved mobility, and options for aging in place, especially for those who may struggle with stairs. Whether you require mobility assistance or simply wish to avoid carrying bulky or heavy items up and down the stairs in your daily routine, the Vuelift Mini home elevator provides comfort and safety.
Level luxury on the next level
As a standalone solution with an integrated shaft, the Vuelift seamlessly integrates into existing architecture. You don't have to sacrifice style for comfort. With a Savaria home lift, you're investing in luxury and comfort for today while ensuring mobility and independence for the future.
